| MACHINE |  Clamping Range |  Machining Range |  Wall Thickness |  Stroke |
|---|
| TU5 | Clamping Range 51mm ID - 200mm ID | Machining Range 51mm ID - 219mm OD | Wall Thickness 2mm to 20mm | Stroke 60mm |
| TYPE |  Motorization |  Power |  Specifications |  Weight |
|---|
| TU5 P | Motorization Pneumatic / 1HP | Power 6Bars (90PSI) | Specifications 1000L/min (35 cfm) | Weight 15kg |
| TU5 E | Motorization Electric / 1400W | Power 230V / 50hertz | Specifications Speed Variator | Weight 17kg |
| TU5 E | Motorization Electric / 1400W | Power 115V / 50hertz | Specifications Speed Variator | Weight 17kg |
| TU5 E | Motorization Electric / 1400W | Power 115V / 60hertz | Specifications Speed Variator | Weight 17kg |
| TU5 B | Motorization Battery | Power 18V | Specifications Charger + 2 batteries | Weight 16kg |
